◆性能安定，吐出量的範圍最為廣泛，低騷音、高效率、省馬力，葉片幫浦、適用於磨床、壓床、褶床、等工作母機、及壓鑄機、塑膠射出機、單能機等油壓機械、尤適用於高低壓油路中之低壓幫浦。
◆型式號碼表示法 / MODEL NUMBER DESIGNATON
??? 50T,150T???????? ?36──?F──R??????
???? ?①? ? ? ? ? ? ? ? ? ? ?②? ? ?③? ? ④
?①?系列號碼Serial Nunber
?②吐出量 Dilivery capacity
?③裝配型式 Assemble model??????F:法蘭型 Frange Type
????????????????????????????????????????????????????L:腳座型 Foot Type
?④?回轉方向 (自軸側觀(guān)之) Direction of Revolving (?Side View of Self??Aligning Bearing)
???????????????????????????????????????????? ?????????????????????????????? ?? R:順時(shí)針?lè )较?/strong>Clock wise Direction
????????????????????????????????????????????????? ?????????????????????????? ? L:反時(shí)針?lè )较?/strong>counter-clockwise direction
◆性能表 / SPECIFICATION
| 型式號碼
MODEL |
吐出容積? cc/rev
DELIVERY CAPACITY |
最高壓力
MAX. PRESSURE kgf/cm2 |
迴轉速度
SPEED r.p.m |
配管尺寸PT
PORTS SIZE |
重量
WEIGHT (kg) |
||||||
| 最低
MIN |
最高
MAX |
入口
IN |
出口
OUT |
腳座型
FOOT TYPE |
法蘭型
FLANGE TYPE |
||||||
| 迴轉速度SPEED( r.p.m) | |||||||||||
| 1000 | 1200 | 1500 | 1800 | ||||||||
| 50T-07 | 7.0 | 8.2 | 10.3 | ?? 12.5 | 70 | 950 | 1800 | 1” | 3/4” | 10.5 | 9 |
| 50T-12 | 12.2. | 14. 3 | 18.2 | 21.5 | |||||||
| 50T-14 | 14.5 | 17. 3 | 21.5 | 26 | |||||||
| 50T-17 | 17.1 | 20.2 | 25.5 | 31.5 | |||||||
| 50T-20 | 20.0 | 23.8 | 29.8 | 36.1 | |||||||
| 50T-23 | 23.1 | 27.4 | 34.3 | 41.3 | |||||||
| 50T-26 | 26.2 | 31.2 | 39.2 | 46.5 | |||||||
| 50T-30 | 30.2 | 36.2 | 45.2 | 54.1 | |||||||
| 50T-36 | 36.2 | 41.5 | 54.5 | 64.2 | |||||||
| 50T-39 | 39.0 | 46.6 | 58.3 | ?1500 | |||||||
| ? 50T-43 | ??? 43 | ?? 51.6 | ? ?64.5 | ?1500 | |||||||
| 150T-48 | 48.2 | 58.0 | 72..6 | 86.4 | 70 | 900 | 1500 | 1?? 1/2” | 1 1/4” | 26 | 25 |
| 150T-61 | 61.4 | 73.8 | 92.0 | 110.6 | |||||||
| 150T-75 | 75.0 | 90.5 | 113.1. | 135.6 | |||||||
| 150T-94 | 94.0 | 113.1 | 141.3 | ||||||||
| 150-116 | 116.2 | 139.5 | 174.2 | ||||||||
| ?150-125 | ?125 | ?150 | ? 187.5 | ||||||||
